Founded in 2014 in MIDC, Satpur, Nashik, Align Industry has become a trusted name in providing top-tier machinery for Papad & Masala manufacturing solutions, relied upon by professionals worldwide.
Established by Mr. Chetan Pawar, a seasoned Chemical Engineer celebrated for his expertise and vision, Align Industry excels in creating a diverse range of essential machinery for these industries. Leveraging state-of-the-art technology and a skilled technical team, we prioritize meticulous processes to ensure the production of superior-quality machinery
Delivering excellence since 2014, Align Industry proudly serves bakery, pharma, poultry, and cattle feed sectors with innovative, reliable, and industry-leading machinery crafted with precision.
.png){kind=icon}
Happy Clients
.png){kind=icon}
Machines Manufactured
.png){kind=icon}
Industries Catered
Hours Of Researach
The Processing Plant is available in capacities ranging from 300 LPH to 30,000 LPH, boasts a regeneration efficiency of 90% and above, constructed with plate materials SS-304 or SS-316. It comes equipped with a fully automatic control system to monitor temperatures, serving multiple purposes including curd, paneer, & high-fat milk processing.
| MASALA MACHINE WITH CYCLONE | 10 HP | 20 HP |
|---|---|---|
| MODEL NO. | AMC1002 | AMC2002 |
| GRINDING CAPACITY PER HRS | 80 TO 100 KG | 150 TO 190 KG |
| AUTOMATION GRADE | SEMI AUTOMATIC | SEMI AUTOMATIC |
| MATERIAL | MS BODY | MS BODY |
| POWER SOURCE | ELECTRIC | ELECTRIC |
| VOLTAGE (V) | 415 | 415 |
| CURRENT (A) | 16 | 28 |
| CORROSION RESISTANCE | YES | YES |
| POWER CONSUMPTION | 9.50KWH | 17.00KWH |
| MOTOR RPM | 1440 | 1440 |
| BEATER (CUTTER) RPM | 3840 | 3840 |
| FREQUENCY (HZ) | 50 | 50 |
| MOTOR TYPE | THREE PHASE | THREE PHASE |
| COATING | POWDER COATING | POWDER COATING |
| CHAMBER | DOUBLE CHAMBER | DOUBLE CHAMBER |
| MACHINE DIMENSION INCH | L-63", W-24", H-50.6" | L-71", W-25", H-55" |
| FRONT CHAMBER DIMENSION INCH | 14" Dia x 8.5" Depth | 16" Dia X 10.5" Depth |
| CYCLONE DIMENSION INCH | L-30", W-30", H-100" | L-30", W-30", H-108" |
| CYCLONE MOTOR | 0.5 & 2 HP | 0.5 & 3 HP |
| MASALA MACHINE | 3 HP | 5 HP |
|---|---|---|
| MODEL NO. | AIM302 | AIM502 |
| GRINDING CAPACITY PER HRS | 30 TO 35 KG | 50 TO 60 KG |
| AUTOMATION GRADE | SEMI AUTOMATIC | SEMI AUTOMATIC |
| MATERIAL | MS BODY | MS BODY |
| POWER SOURCE | ELECTRIC | ELECTRIC |
| VOLTAGE (V) | 415 | 415 |
| CURRENT (A) | 4.5 | 7.5 |
| CORROSION RESISTANCE | YES | YES |
| POWER CONSUMPTION | 2.50KWH | 4.00KWH |
| MOTOR RPM | 1440 | 1440 |
| BEATER (CUTTER) RPM | 3840 | 3840 |
| FREQUENCY (HZ) | 50 | 50 |
| MOTOR TYPE | THREE PHASE | THREE PHASE |
| COATING | POWDER COATING | POWDER COATING |
| CHAMBER | DOUBLE CHAMBER | DOUBLE CHAMBER |
| MACHINE DIMENSION INCH | L-51", W-20", H-44" | L-54", W-20", H-46" |
| FRONT CHAMBER DIMENSION INCH | 10" Dia x 5" Depth | 10" Dia X 6.5" Depth |
| MODEL | AIM5 | AIM5A | AIM5AV |
|---|---|---|---|
| PRODUCTION | 500 Pcs/Hr | 500 Pcs/Hr | 500 Pcs/Hr |
| MOTOR | 0.25 HP | 0.25 HP | 0.25 HP |
| ATTA COLL. TRAY | NO | YES | YES |
| SPEED CONTROL | NO | NO | YES |
| MODEL | AIM8 | AIM8A | AIM8AV |
|---|---|---|---|
| PRODUCTION | 800-1000 Pcs/Hr | 800-1000Pcs/Hr | 800-1000Pcs/Hr |
| MOTOR | 0.5 HP | 0.5 HP | 0.5 HP |
| ATTA COLL. TRAY | YES | YES | YES |
| SPEED CONTROL | YES | NO | YES |
| MODEL | AIM12 | AIM12A | AIM12AV |
|---|---|---|---|
| PRODUCTION | 1200-1400Pcs/Hr | 1200-1400Pcs/Hr | 1200-1400Pcs/Hr |
| MOTOR | 1 HP | 1 HP | HP |
| ATTA COLL. TRAY | NO | YES | YES |
| SPEED CONTROL | NO | NO | YES |
Providing tailored solutions across diverse sectors like Bakery, Dairy, Pharma, Cosmetics, and Cattle Feed.
